Screw oil presses / TECHNICAL PROFILE

VG-80

Compact screw oil press

A compact screw press for businesses planning small-scale oilseed processing. The supplied technical sheet lists a rapeseed feed capacity of 80–160 kg/h, a 5.5 kW main motor and a 3 kW heater. Confirm preparation and filtration needs for your material.

SEED FEED RATE80–160 kg/h · rapeseed

MAIN DRIVE5.5 kW

Discuss this machine ↗Technical specifications ↓

DESIGNED AROUND THE DETAILS

Know your
configuration.

Final selection depends on your raw material and operating conditions. We confirm the complete technical scope before an order.

VG-80 specifications
Reference material	Rapeseed
Seed feed capacity	80–160 kg/h
Main motor	5.5 kW, 6-pole
Heater	3 kW
Screw diameter	80 mm
Screw speed	71 rpm
Press chamber internal diameter	82 mm
Overall dimensions (L × W × H)	1520 × 910 × 1520 mm
Machine weight	435 kg
Standard electrical supply	3-phase 380 V / 50 Hz; confirm before order
Hopper & oil tray	304 stainless steel

Feed capacity is not oil yield. Dimensions and configuration must be confirmed for the supplied machine.

MATERIAL FIRST

Match the seed.
Then size the press.

Use the VG-80 reference data as a starting point, not a guarantee for every oilseed or process.

REFERENCE FEED CAPACITY

80–160 kg/h · rapeseed

The listed figure describes seed input, not finished oil output. Confirm the reference material and configuration in the specification table above.

Share the seed variety, moisture information and cleaning or conditioning method.
State your target seed input per hour and planned daily operating hours.
Agree on material preparation and operating conditions before selecting the machine.

The available capacity references do not specify a complete test protocol. Exact moisture targets, conditioning temperatures and guaranteed output need confirmation for your material; no trial results are implied here.

OTHER OILSEEDS / PROJECT REVIEW

Discuss suitability before ordering.

For peanut, sunflower or sesame projects, confirm material preparation and model suitability with the equipment team. A rapeseed feed rate must not be reused as a guaranteed rate for another seed.

Peanut: discuss shelling, clean kernels and conditioning.
Sunflower: discuss variety, hull content and whether dehulling is appropriate.
Sesame: discuss cleaning, conditioning and the intended oil characteristics.

Where performance is uncertain, request a material trial and agree what will be measured.

Read oilseed preparation guides

DEFINE THE SUPPLY SCOPE

The press.
The supporting equipment.

Separate the listed machine configuration from project-specific additions. Final inclusion is governed by the confirmed technical scope, not by a photograph.

LISTED PRESS CONFIGURATION

VG-80

Main drive: 5.5 kW
Heater: 3 kW
Standard electrical supply: 3-phase 380 V / 50 Hz; confirm before order
Hopper & oil tray: 304 stainless steel

The full table above remains the reference for the machine dimensions, weight and mechanical specifications.

OPTIONAL / TO BE AGREED SEPARATELY

Confirm preparation and filtration

The supplied machine reference does not establish an included filtration unit. Ask for a separate filtration selection matched to your oil flow; do not apply another model's filter specification to this press.

Confirm seed preparation equipment, oil collection, filtration, commissioning arrangements and wear-part supply individually before an order. Filtration alone is not refining or proof of food-standard compliance.

Confirm the supply scope for VG-80

BEFORE DELIVERY

Prepare the site.
Plan the upkeep.

A procurement checklist, not an installation or operating manual. Machine-specific settings and procedures must come from the approved documents for the supplied configuration.

ELECTRICAL

Confirm your local supply.

3-phase 380 V / 50 Hz; confirm before order

Provide your phase, voltage and frequency before ordering. A different supply requires engineering confirmation; no alternate-voltage version is promised on this page.

Main motor power is not a complete site-load specification. Have qualified personnel confirm wiring, earthing, protection and the requirements of heaters and any auxiliary equipment.

LAYOUT & COMMISSIONING

Check access and working space.

Use the listed machine dimensions for initial planning, then request the approved layout and foundation or anchoring requirements.

Check delivery access, equipment placement and ventilation.
Confirm space for feeding, oil collection, filtration and maintenance.
Agree on operator training and commissioning responsibilities.

No installation clearance or foundation design is specified here.

MAINTENANCE

Request the supplied manual.

Confirm cleaning access, wear-part identification, spare-part availability and the maintenance schedule for the supplied machine.

Isolate and lock out power before maintenance. Follow the actual machine instructions and use qualified personnel where required.

Lubricants, adjustment settings and service intervals are not specified in the available product references. Obtain these from the machine manual, not from a generic website checklist.

SUPPLIED PROCESS FOOTAGE

See the process.
Verify your configuration.

These supplied videos show pressing, oil collection and factory demonstrations. Exact model mapping and test conditions have not been confirmed; none is presented as a VG-80 acceptance test or a capacity guarantee.

Pressing and cake-discharge reference

Supplied footage of feeding, oil collection and press cake. The dark seed is not assigned a crop name here, and the machine is not claimed to be this page’s model.

Process reference only, not a safe-work demonstration. Do not copy adjustments around exposed moving or hot parts. Follow the supplied manual, keep guards in place and use trained personnel.

Seed feeding and oil-flow reference

Hopper and oil-collection views. Model, material identity and performance conditions remain unconfirmed.

Factory demonstration reference

A supplied on-site demonstration showing loading and pressing. People appearing in the clip are not presented as verified customers or a testimonial.

Installation and operation overview — reference only

For qualified personnel and model-specific review. The video shows an example configuration, including filtration. Do not apply its cable sizing, lubrication levels, temperatures, rotation checks or control sequence to VG-80 without the approved manual and electrical drawings. Isolate and lock out power before wiring or servicing.

Supplied installation and operation overview

The original bilingual subtitles and audio are retained; the upper-right overlay has been locally removed and that small area is visually softened. This edited reference is not the installation manual for this model. Original subtitles are not independently validated technical instructions.

Existing sesame process reference

The model in the clip has not been confirmed; it is not presented as a VG-80 performance test.

Supplied sesame process footage. Confirm the model and trial conditions before using any video to assess your project. No oil-yield or throughput claim is derived from this clip.

About the product images and model-specific evidence

Bundled product and component images are retouched visual references. They are not approved engineering drawings or evidence of wiring, safety compliance or the final supplied assembly. Request current, unretouched photographs and a model-confirmed running video when discussing your configuration.

YOUR PROJECT / VG-80

Send the details
that shape the selection.

The inquiry form will preselect VG-80. Include the following so the discussion starts with your process, not just a model name.

Raw material, preparation method and available moisture information.
Target seed input per hour and planned operating hours.
Installation country, phase, voltage and frequency.
Required filtration, oil collection and supporting equipment.
Requests for the current configuration photos, model-confirmed video, manual and wear-part list.
